| Switcher Channels |
14 – 6 external, 4 internal, 4 virtual inputs |
| Video Input |
4 simultaneous live video sources, in any combination of HD Component, SD Component, Y/C or Composite and supported resolutions
- Each input includes integrated frame synchronizer
- Independent keying, cropping, Proc Amp and white balance controls per input
- BNC connectivity
|
| Network Sources |
2 simultaneous live sources via Gigabit connection, selectable from any available network sources
- Supported sources include networked computers via included NewTek iVGA client application; wireless Apple® AirPlay® devices; NewTek TriCaster and 3Play systems with A/V network output; TalkShow; LiveText; and a variety of third-party partner solutions
|
| Media |
3 integrated digital media sources for video and graphics (DDR and 2 GFX)
- LiveText character generator for custom titles and graphics
|
| Virtual Inputs |
4 independent, mix/effect-style channels supporting multi-source compositions, virtual sets, double-box effects and more
- 3 configurable sources per channel, each with independent positioning, scaling and cropping, including upstream keyer with DVE and transition controls
|
| Downstream Key |
2 downstream keyers, each with independent DVE, transition controls, positioning and scaling |
| Effects and Transitions |
Integrated TransWarp effects engine on all effects channels supports standard transitions, customizable animation store transitions with audio, and overlay effects
- Animation Store Creator for custom animations
- Supports per-pixel alpha blending between sources and real-time 3D warping of video or graphics
|
| Virtual Sets |
24 HD live virtual sets, with multiple camera angles, real-time reflections, specular highlights, animated zoom and presets |
| Video Output |
A/V output signal through up to 5 output connections
- 2 x Analog (BNC; configurable for Component or Y/C + Composite; PGM and SD-only AUX)
- Network output for live streaming
|
| Recording |
Native recording in resolutions up to 1080p
- Record source selectable from among Program, Aux, or any individual camera input
- Encoding format selectable from among QuickTime®, MPEG-2 (high or normal profile), AVI (Speed HQ), and H.264 (high or Web-quality)
|
| Recording Capacity |
Accommodates ~ 20 hours 1080i or ~ 120 hours 480i via internal drive in QuickTime format
- Capacity expandable using external media drives
|
| Live Streaming |
HD live streaming via Adobe® Flash® or Microsoft® Windows Media® Push/Pull |
| Audio Inputs |
1 x 1/4” (mono; mic)
2 x RCA (stereo L/R; line) |
| Audio Outputs |
2 x RCA (stereo L/R; line)
1 x 1/4” (stereo; phones) |
| Audio Mixing |
Integrated multi-channel audio mixer for internal and external audio sources, effects, output, stream and headphones |
| Supported Formats |
NTSC model: 1080/30p, 1080/24p, 1080/60i, 720/60p, 720/30p, 720/24p, 480i (16:9 or 4:3) Multi-Standard model also includes equivalent NTSC-J and PAL selections |
| Playback Media Formats |
AVI, DV, DVCPro, DVCProHD, FLV, F4V, H.263, H.264, MOV, MKV, MJPEG, MPEG (1, 2, all profiles, program or transport streams), MP4, WMV, WebM, PSD, PNG, TGA, BMP, JPEG, EXR, RAW, TIF, AIFF, MP3, WAV, and more, with Import Media application for batch import with optional transcoding of files (including Apple ProRes) |
| Export Media Formats |
Export media application for batch copying with optional transcoding of files to compatible formats for different applications and devices: AVI, DV, DVCPro, DVD, H.264, MOV, MPEG-2, MJPEG, MP4, WebM and more
- Presets for Non-Linear Editors: Adobe Premiere®, Apple® Final Cut Pro®, and more
- Presets for mobile platforms: Android®, iPad®, iPhone®, iPod Touch® and more
|
| Monitoring |
DVI and HDMI monitor outputs for user interface and multiview preview, with selectable layouts |
| Signal Monitoring |
Integrated Waveform and Vectorscope, full field rate with color preview and support for ITU-R Rec. 601 and 709 |
| Processing |
Video: 4:4:4:4, 32-bit Floating Point
Audio: 2 channels, 96 kHz, 32-bit Floating Point |
| System Physical |
10.4 x 8.5 x 17.5 in (26.4 x 21.6 x 44.5 cm)
19 lbs (8.6 kg) |
